6–6 PQMII POWER QUALITY METER – INSTRUCTION MANUAL
CHAPTER 6: MONITORING
6.2.2 Voltage Metering
PATH: ACTUAL VALUES Ö A1 METERING ÖØ VOLTAGE
 VOLTAGE [Z] Van = 120 Vbn = 120
Vcn = 120 V
MESSAGE
Iavg = 100 AMPS
Vavg = 120 V L-N
MESSAGE
Vab= 0 Vbc= 0
Vca= 0 V
MESSAGE
AVERAGE LINE
VOLTAGE = 208 V
MESSAGE
VOLTAGE UNBALANCE =
0.0%
MESSAGE
Van MIN = 100 V
12:00:00am 01/01/95
MESSAGE
Vbn MIN = 100 V
12:00:00am 01/01/95
MESSAGE
Vcn MIN = 100 V
12:00:00am 01/01/95
MESSAGE
Vab MIN = 173 V
12:00:00am 01/01/95
MESSAGE
Vbc MIN = 173 V
12:00:00am 01/01/95
MESSAGE
Vca MIN = 173 V
12:00:00am 01/01/95
MESSAGE
V U/B MIN = 0.0%
12:00:00am 01/01/95
MESSAGE
Van MAX = 140 V
12:00:00am 01/01/95
MESSAGE
Vbn MAX = 140 V
12:00:00am 01/01/95
MESSAGE
Vcn MAX = 140 V
12:00:00am 01/01/95
MESSAGE
Vab MAX = 242 V
12:00:00am 01/01/95
MESSAGE
Vbc MAX = 242 V
12:00:00am 01/01/95
MESSAGE
Vca MAX = 242 V
12:00:00am 01/01/95
MESSAGE
V U/B MAX = 5.1%
12:00:00am 01/01/95
