– 14 –
Main Board
Inverter Board
Inverter and Main Board Pin Connectors
Lid Switch
Thermistor
Clutch Motor
Ground
Power LED
Hall Sensor
Water Valve Assembly
Pressure Sensor
Washer Motor
Drain Pump
Brake Resistor
Main Board CON2
Main Board CON1
120 VAC Input From RF Choke
LCD Display
Power Switch
Cable 1 to CON2
Cable 2 to CON1
