Chapter 2. Getting Started
GFK-2847 QuickPanel+ User’s Manual–November 2013 11
Gasket, one (not shown, pre-installed)
Figure 2. QuickPanel+ Package Contents
2.2 Basic Setup
Your QuickPanel+ is shipped ready for use after a few configuration steps. To power up, all
you need to do is connect a DC power supply using the supplied quick-connect plug.
Depending on your application, you may also want to connect and configure optional input
devices, communications ports and expansion adapters.
Figure 3. Basic Setup Diagram
Warning
Electrical Shock Hazard: To avoid personal injury or damage to
equipment, ensure that the DC supply is disconnected from power
and that the leads are not energized before attaching them to
the unit's power supply plug.
2.3 Startup
You will need the following:
