GE MEDICAL SYSTEMS
P9030GX
RTfino/RT3200 Advantage–II/RT–x200 SERVICE MANUAL
RENEWAL PARTS9–45
REV 25
OPERATOR CSL ASSY FOR PAL SHORT MODEL
P9515CA, P9515CC, P9515CD, P9515CF, P9515CG, P9515CH,
2163995 (P9515CJ)
MATERIAL LIST (8/10)
ITEM PART NAME PART NO. QTY. DESCRIPTION
251 RFL ASSY P9514WA 1 FOR P9515CA
RFL–A ASSY P9514XA 1 FOR P9515CC,CD,CF,CG, CH, CJ
252 RRS ASSY P9514WC 1 FOR P9515CA
RRS–A ASSY P9514XC 1 FOR P9515CC,CD,CF,CG, CH, CJ
253 TRC ASSY P9515WE 1 FOR P9515CA
TRC–A ASSY P9514XE 1 FOR P9515CC, CD
TRC–B ASSY P9514YF 1 FOR P9515CF
TRC–D ASSY P9514YE 1 FOR P9515CG
P9514YB TRC–E5 2113949 1 FOR P9515CH, CJ
254 MST–E ASSY P9514XJ 1 FOR P9515CA
MST–E2 ASSY P9514XH 1 FOR P9515CC, CD
MST–E4 ASSY P9514ZZ 1 FOR P9515CF, CG
P9514ZC MST–E5 2113953–4 1 FOR P9515CH
P9514ZM MST–E6 ASSY 2159933 1 FOR P9515CJ
255 SCC–P ASSY P9514XK 1
256 FM–P ASSY P9514XM 1 FOR P9515CA
FM–PA ASSY P9514YM 1 FOR P9515CC,CD,CF,CG, CH, CJ
257 VDO–P ASSY P9514XP 1 FOR P9515CA
VDO–PA ASSY P9514YP 1 FOR P9515CC,CD,CF,CG, CH, CJ
258 MOTHER B’d ASSY P9514WT 1
259 CONN B’d ASSY P9514WV 1 FOR P9515CA,CC
P9514XV 1 FOR P9515CD,CF,CG, CH, CJ
260 HV ASSY P9514WX 1
281 XFMR ASSY P9514JL 1
282 SW REGULATOR U0219EE 1 RT–3–5FF
283 SW REGULATOR U0231EE 1 K100AU–5
SW REGULATOR 2222324 1 R100U–5, including PS SPRT4 (
P9514DM Rev.1)
284 SW REGULATOR U0261EE 1 K50AU–12
SW REGULATOR 2222325 1 R50U–12, including PS SPRT3 (
P9514DL Rev.1)
285 SW REGULATOR U0262EE 1 K10AU–5
SW REGULATOR 2222326 1 R15U–5, including PS SPRT1 (
P9514DJ Rev.1)
Note
Three types of the SW Regulators (Items 283, 284, and 285) change to new ones because of the
discontinuance of parts. You can replace old SW Regulator with new one using modified PS SPRT
supplied with each new SW Regulator.
