GE MEDICAL SYSTEMS
P9030GX
RTfino/RT3200 Advantage–II/RT–x200 SERVICE MANUAL
RENEWAL PARTS9–46
REV 25
OPERATOR CSL ASSY FOR PAL SHORT MODEL
P9515CA, P9515CC, P9515CD, P9515CF, P9515CG, P9515CH,
2163995 (P9515CJ)
MATERIAL LIST (9/10)
ITEM PART NAME PART NO. QTY. DESCRIPTION
286 CIRCUIT PROTECTOR U0024EK 2 0.5A
288 CIRCUIT PROTECTOR U0043EK 2 5A
289 CIRCUIT PROTECTOR U0043EK 1 5A
290 TERMINAL U0002FP 2 6
291 TERMINAL U0003FP 1 12
292 TERMINAL U0108FP 1 3
293 NAME PLATE Z9814PX 1 A+5V
294 POWER SW ASSY P9515XZ 1
295 TROIDAL CORE U0012MC 5 TR–28–16–13
296 DISCON PLATE P9500DZ 1
297 NAME PLATE Z9814QX 1 G
298 NAME PLATE Z9814QY 1 D+5V
299 NAME PLATE Z9814QZ 1 D+12V
301 CABLE ASSY 2 P9515VB 1
302 CABLE ASSY 3 P9515VC 1
303 CABLE ASSY 4 P9515VD 1
304 CABLE ASSY 5 P9515VE 2
305 CABLE ASSY 6 P9515VF 1
306 CABLE ASSY 7 P9515VG 1
309 CABLE ASSY 10 P9515VK 1
310 CABLE ASSY 11 P9515VL 1
312 CABLE ASSY 13 P9515VN 1
313 CABLE ASSY 14 P9515VP 1
314 CABLE ASSY 15 P9515VQ 1
315 CABLE ASSY 16 P9515VR 1
316 CABLE ASSY 17 P9515VS 1
317 CABLE ASSY 18 P9515VT 1
318 CABLE ASSY 19 P9515VU 1
319 CABLE ASSY 20 P9515VV 1
320 CABLE ASSY 21 P9515VW 1
321 CABLE ASSY 22 P9515VX 1
