GE MEDICAL SYSTEMS
P9030GX
RTfino/RT3200 Advantage–II/RT–x200 SERVICE MANUAL
RENEWAL PARTS9–81
REV 25
OPERATOR CSL ASSY FOR 115V NTSC SHORT MODEL
P9515FA, FB, FC, FD, FE, FF, FG, FH, FJ, FK, FL, FM, FN, FP
MATERIAL LIST (8/10)
ITEM PART NAME PART NO. QTY. DESCRIPTION
251 RFL ASSY P9514WA 1 FOR P9515FA, FB, FC, FD
RFL–A ASSY P9514XA 1 FOR P9515FE, FF, FG, FH, FJ, FK, FL, FM
FOR P9515FN, FP
252 RRS ASSY P9514WC 1 FOR P9515FA, FB, FC, FD
RRS–A ASSY P9514XC 1 FOR P9515FE, FF, FG, FH, FJ, FK, FL, FM
FOR P9515FN, FP
253 TRC ASSY P9514WE 1 FOR P9515FA, FB, FC, FD
TRC–A ASSY P9514XE 1 FOR P9515FE, FF, FG, FH, FJ, FK
TRC–C ASSY P9514XZ 1 FOR P9515FL, FM
P9514YC TRC–J5 2113950 1 FOR P9515FN, FP
254 MST–J ASSY P9514WG 1 FOR P9515FA, FB, FC, FD
MST–J2 ASSY P9514YG 1 FOR P9515FE, FF, FG, FH
MST–J3 ASSY P9514ZQ 1 FOR P9515FJ, FK
MST–J4 ASSY P9514ZW 1 FOR P9515FL,FM
P9514ZE MST–J5 2113955–5 1 FOR P9515FN, FP
255 SCC–N ASSY P9514WK 1
256 FM–N ASSY P9514WN 1 FOR P9515FA, FB, FC, FD
FM–NA ASSY P9514XN 1 FOR P9515FE, FF, FG, FH, FJ, FK, FL, FM
FOR P9515FN, FP
257 VDO–N ASSY P9514WP 1 FOR P9515FA, FB, FC, FD
VDO–N2 ASSY P9514YQ 1 FOR P9515FE, FF, FG, FH, FJ, FK, FL, FM
FOR P9515FN, FP
258 MOTHER B’d ASSY P9514WT 1
259 CONN B’d ASSY P9514WV 1
260 HV ASSY P9514WX 1
281 XFMR ASSY P9514JL 1
282 SW REGULATOR U0219EE 1 RT–3–5FF
283 SW REGULATOR U0231EE 1 K100AU–5
SW REGULATOR 2222324 1 R100U–5, including PS SPRT4 (
P9514DM Rev.1)
284 SW REGULATOR U0261EE 1 K50AU–12
SW REGULATOR 2222325 1 R50U–12, including PS SPRT3 (P9514DL Rev.1)
285 SW REGULATOR U0262EE 1 K10AU–5
SW REGULATOR 2222326 1 R15U–5, including PS SPRT1 (P9514DJ Rev.1)
Note
Three types of the SW Regulators (Items 283, 284, and 285) change to new ones because of the
discontinuance of parts. You can replace old SW Regulator with new one using modified PS SPRT
supplied with each new SW Regulator.
To Next Page
