GE MEDICAL SYSTEMS
P9030GX
RTfino/RT3200 Advantage–II/RT–x200 SERVICE MANUAL
RENEWAL PARTS9–82
REV 25
OPERATOR CSL ASSY FOR 115V NTSC SHORT MODEL
P9515FA, FB, FC, FD, FE, FF, FG, FH, FJ, FK, FL, FM, FN, FP
MATERIAL LIST (9/10)
ITEM PART NAME PART NO. QTY. DESCRIPTION
286 CIRCUIT PROTECTOR U0025EK 2 1A
288 CIRCUIT PROTECTOR U0040EK 2 10A
289 CIRCUIT PROTECTOR U0043EK 1 5A
290 TERMINAL U0002FP 2 6
291 TERMINAL U0003FP 1 12
292 TERMINAL U0020FP 1 3
293 NAME PLATE Z9814PX 1 FOR P9515FE, FF, FG, FH, FJ, FK, FL, FM
FOR P9515FN, FP
294 POWER SW ASSY P9515XZ 1
295 TROIDAL CORE U0012MC 5 TR–28–16–13
297 NAME PLATE Z9814QX 1 G
298 NAME PLATE Z9814QY 1 D+5V
299 NAME PLATE Z9814QZ 1 D+12V
300 CABLE ASSY 1 P9515VA 1
302 CABLE ASSY 3 P9515VC 1
303 CABLE ASSY 4 P9515VD 1
304 CABLE ASSY 5 P9515VE 2
305 CABLE ASSY 6 P9515VF 1
306 CABLE ASSY 7 P9515VG 1
307 CABLE ASSY 8 P9515VH 1
308 CABLE ASSY 9 P9515VJ 1
309 CABLE ASSY 10 P9515VK 1
310 CABLE ASSY 11 P9515VL 1
312 CABLE ASSY 13 P9515VN 1
313 CABLE ASSY 14 P9515VP 1
314 CABLE ASSY 15 P9515VQ 1
315 CABLE ASSY 16 P9515VR 1
316 CABLE ASSY 17 P9515VS 1
317 CABLE ASSY 18 P9515VT 1
318 CABLE ASSY 19 P9515VU 1
319 CABLE ASSY 20 P9515VV 1
320 CABLE ASSY 21 P9515VW 1
321 CABLE ASSY 22 P9515VX 1
To Next Page
