GE T2100 Service Manual

FRUReplacement
PIN
Description
R2&R1
Whitewiresgoingtotheresistor.Thesewirescanbeinverted.
W
Bluewiregoingtothedrivemotor.
V
Redwiregoingtothedrivemotor.
U
Blackwiregoingtothedrivemotor.
L3
Notused.
L2
BlackwiregoingtotheL2terminalonthepowerboard.
L1
BlackwiregoingtotheL1terminalonthepowerboard.
NC
Notused.
Gnd
Orange-Yellowwireearth/groundgoingtothemotor.Canbeinvertedwith
theotherGnd.
Gnd
Orangewireearth/groundgoingtothegroundterminalonthepowerboard.
CanbeinvertedwiththeotherGnd.
ElevationPotentiometerReplacement
ReplacetheElevationPotentiometerHarnessonT2100Treadmillsexperiencing
elevationhesitationandseekingproblemsorafaultyT2100Treadmillstopcondition
duringanelevationchange.
122
T2100Treadmill
2021403-120F
