EquipmentOverview
ConnectionPanel
Thefollowingillustrationdescribestheconnectorsontheconnectionpanelofthe
T2100Treadmill,andidentiesthegenerallocationoftheserialnumber.
Item
Description
1
RS232SerialPort
2
RS422SerialPort
3
CalibrationButton
4
Theserialnumberstickerisafxedtotherightinsidelipoftheconnectionpanel.
5
ReferencedesignatorF3T0.5AL,250V
GEpartnumber1910–012
6
ReferencedesignatorF5T0.5AL,250V
GEpartnumber1910–012
7
ACPowerConnection
200–240V,50–60Hz
8
ON/OFFSwitch
9
Equipotential(groundlug)
10
EmergencyStopSwitchConnection
2021403-120F
T2100Treadmill
35
