IRECTION GB091046, REVISION 2 VIVID E9 / VIVID E7 BT’13 SERVICE MANUAL
Chapter 5 - Components and functions (theory) 5 - 15
Section 5-4
Top Console with LCD monitor and Operator Panel
5-4-1 Top Console description
5-4-1-1 Introduction
The Top Console includes:
• LCD monitor on an adjustable arm
• Operator Panel with;
- an ON/OFF switch
- a touch screen and a switch board with controls for manipulating the picture quality and for
use in Measure & Analyze (M&A)
- an alphanumeric keyboard (QWERTY keyboard) on a drawer below the switch board.
• speakers for stereo sound output used during Doppler scanning/replay
5-4-1-2 Connection between the Top Console and the rest of the VIVID E9 / VIVID E7
A flexible harness of electrical wires secures the connection between the Top Console and the rest of
the VIVID E9 / VIVID E7.
