IRECTION GB091046, REVISION 2 VIVID E9 / VIVID E7 BT’13 SERVICE MANUAL
8 - 176 Section 8-8 - Main Console parts replacement
Section 8-8
Main Console parts replacement
8-8-1 Purpose of this section
This section describes how to replace the replaceable parts in the Main Console.
8-8-2 Rear Filter and “handle type” Bottom Filter replacement
8-8-2-1 Preparations
When preparing for the replacement, you must perform the following steps:
1.) Power down the VIVID E9 / VIVID E7.
2.) Disconnect the Mains Power Cable from the wall outlet.
3.) Disconnect all probes and external I/O cabling.
4.) Remove the Filter Cover.
