IRECTION GB091046, REVISION 2 VIVID E9 / VIVID E7 BT’13 SERVICE MANUAL
8 - 28 Section 8-5 - Replacing Covers and Bumpers
8-5-3-2 Top Cover removal procedure
Follow these steps to remove the Top Cover:
1.) Remove two screws.
2.) Remove the Top Cover.
Figure 8-8 Top Cover fixing screws (seen from above)
