IRECTION GB091046, REVISION 2 VIVID E9 / VIVID E7 BT’13 SERVICE MANUAL
8 - 154 Section 8-6 - Top Console Parts Replacement Overview
8-6-33 Replacing the Probe Holder Inserts
8-6-33-1 Introduction
The Probe Holder Inserts are soft rubber inserts, used to protect the probes from scratches, when stored
on the VIVID E9 / VIVID E7. You can place the Probe Holder Inserts in any of the desired places on the
edge of the Operator Panel. The following types of inserts are available:
• Probe Holder Insert STD
• Probe Holder Insert 3D
• Probe Holder Softinsert Doppler
8-6-33-2 Manpower
One person, 1 minute.
8-6-33-3 Tools
No tools needed.
8-6-33-4 Preparations
1.) Disconnect and remove all the probes.
2.) Store the probes in a safe place.
8-6-33-5 Removal
To remove a Probe Holder Insert, grab it and pull or push it upwards.
8-6-33-6 Installation
To install a Probe Holder Insert, place it so it fits one of the probe positions on the side of the Operator
Panel.
Figure 8-135 Probe holders (used on both sides)
PROBEHOLDER, DOPPLER
PROBEHOLDER, 3D/4D
PROBEHOLDER, STANDARD
