IRECTION GB091046, REVISION 2 VIVID E9 / VIVID E7 BT’13 SERVICE MANUAL
8 - 196 Section 8-9 - Casters and Brakes replacement
8-9-1-4 Rear Casters installation procedure
1.) Position the Caster so it align with the hole for the fixing bolt.
2.) Install the fixing bolt (M12 X 40 mm). Use a 10 mm HEX key, Torque: 130 Nm.
3.) Remove the Wooden Wedge.
4.) Roll the VIVID E9 / VIVID E7 off the Bevel Edged Board.
5.) To replace the other Rear Caster, repeat all the steps, starting from 8-9-1-3 "Rear Casters removal
procedure" on page 8-195, but now using the Bevel Edged board and the Wooden Wedge on the
other side of the VIVID E9 / VIVID E7.
6.) Install the Rear Cover.
7.) Install the Rear Bumper.
8.) Install the Side Covers.
