IRECTION GB091046, REVISION 2 VIVID E9 / VIVID E7 BT’13 SERVICE MANUAL
Chapter 8 - Replacement procedures 8 - 203
8-9-4-2 Brake Pedal installation procedure
1.) Position the Brake Pedal so you can install the fixing screws.
2.) Install the four fixing screws.
8-9-5 Pedal Release replacement
This pedal, placed in the middle, is fixed with three screws. With this in mind, please refer to 8-9-4
"Brake Pedal replacement" on page 8-202 for replacement instructions.
8-9-6 Pedal Dir Lock replacement
This pedal is fixed to the Pedal Mechanism in the same manner as the Brake Pedal. With this in mind,
please refer to 8-9-4 "Brake Pedal replacement" on page 8-202 for replacement instructions.
