GE
D
IRECTION GB091046, REVISION 2 VIVID E9 / VIVID E7 BT’13 SERVICE MANUAL
Chapter 8 - Replacement procedures 8 - 205
8-10-1 Front End parts overview
The table below list the positions of the cards. Position #1 is nearest the probe connectors (front of unit).
Table 8-11 FEP Cards per VIVID E9 / VIVID E7
CARD
POSITION
ABBREVIA-
TION CARD NAME
TOTAL NUMBER OF CARDS
PER SYSTEM
XDclear
SW v113.x
1RLY
RELAY BOARD
1x
2GRX64
ANALOG RECEIVER
BOARD
1x
3GRX128
ANALOG RECEIVER
BOARD
1x
4 GTX-TLP192
TRANSMITTER BOARD
1x
5 NOT USED
EMPTY
NOT USED
6 NOT USED
EMPTY
NOT USED
7 NOT USED
EMPTY
NOT USED
9 DRX
EMPTY
NOT USED
9 DRX
DIGITAL RECEIVER
BOARD
3x
10 DRX
DIGITAL RECEIVER
BOARD
11 DRX
DIGITAL RECEIVER
BOARD
12 GFI
GLOBAL RADIO
FREQUENCY
INTERFACE
1x
N/A
FRONT PLANE
/
XD BUS FOR
GTX-TLP192
THE FRONT PLANE
BOARDS CONNECT TO
THE BACK OF THE
RELAY BOARD, THE GTX
BOARD(S) AND THE GRX
BOARDS
2x
