Chapter 9 - Renewal parts 9 - 19
5.
USB Connector Board 2
GA200717
Going OBSOLETE
1 N Y
6.
HIGH VOLTAGE INVERTER BOARD
WITH CABLE
(Replaces GA200442)
5207000-6 1NY
7.
HIGH VOLTAGE INVERTER BOARD
WITH CABLE
GA200442
Going
OBSOLETE.
1NY
PCB FRUs on the Lower OP
8.
Lower Switch Board with Elastomer GA200440 1 N Y
9.
Encoder Board GA200443 1 N Y
10.
Encoder w. Push Button 066E2306
Replaces GA200447.
5 N Y
Table 9-12 Top Console PCBs (cont’d) sheet 2 of 3
ITEM PART NAME PART NUMBER DESCRIPTION QTY CRU FRU
INTERFACE CABLE
INCLUDED
5.
6.
ERG BRAND
HV INVERTER
