Components and Functions (Theory)
5-28 Vivid E80/E90/E95 – Service Manual
GC091052
Rev. 3
Relay board (GRLY)
GRLY location
Figure 5-14. Location
The Relay board is located in the Front End Rack on the end
nearest to the front of the Vivid E80/E90/E95.
LEDs
Figure 5-15. LEDs on the Relay board
Table 5-4: LEDs on the Relay board
LED Color Description Comments
DS1 Green STATUS_LED Green when probe is present in
connector #4
