GEA ECOspace User Manual

Technical data: Ambient temperatures
Designation Description
- Control top type T.VIS M-15, A-15 -20 to +50 °C (-4 ... +122 °F)
- Control top type T.VIS P-15 0 to +50 °C (-4 ... +122 °F)
Product and operating temperature -40 to +135°C
Technical data: Compressed air supply
Designation Description
Air hose
- metric
Material PE-LD outside Ø 6 mm
Inside Ø 4 mm
- Inch
Material PA outside-Ø 6.35 mm
Inside Ø 4.3 mm
Product pressure max. 10 bar (116 psi)
Control air pressure
min. 4.8 bar
max. 8 bar
Control air pressure for air/air - A/A
actuator
min. 4.0 bar
max. 8 bar
Control air acc. to ISO 8573
- Solid particle content:
Quality class 6
Particle size max. 5 µm
Particle density max. 5 mg/m
3
- Water content:
Quality class 4 max. dew point +3 °C
If the unit is used at higher altitudes or
at low ambient temperatures, the dew
point must be adapted accordingly.
- Oil content:
Quality class 3, ideally oil-free, max.
1 mg oil for 1 m
3
air
Air requirement per switching operation
Actuator type Actuator diameter [mm]
Air requirement (dm
3
n
/
stroke)
dm
3
n
with 1.01325 bar
at 0 °C as per DIN 1343
"DN 50, DN 65 2" OD,
2.5" OD"
88.9 0.325
"DN 80, DN 100 3" OD,
4" OD"
114.3 0.530
Technical data
Technical data
430BAL010337EN_7
24 29.07.2021
