Actuator type Actuator Ø (mm)
Air requirement (dm
3
n
/
stroke) dm
3
n
at 1.01325
bar at 0°C in
accordance with
DIN 1343
DN 50, DN 65
2" OD, 2.5" OD
88.9 0.325
DN 80, DN 100
3" OD, 4" OD
114.3 0.530
6.3.2 Establishing Hose Connections
To ensure reliable operation, the compressed air hoses must be cut exactly
square.
Tools required:
•
A hose cutter
Carry out the following steps:
1.
Shut off the compressed air supply.
2.
Use the hose cutter to cut the pneumatic hoses square.
®
Done.
6.3.3 Actuator with T.VIS Control Top
Carry out the following steps:
1.
Push the air hose into the air connector on the control top.
2.
Re-open the compressed air supply.
®
Done.
6.3.4 Actuator without Control Top
Carry out the following steps:
1.
Remove the plug from the actuator.
2.
Screw in connector G 1/8" or an exhaust air throttle for slow closing.
3.
Push the air hose into the air connector.
4.
Re-open the compressed air supply.
®
Done.
6.4 Electrical connections
Assembly and installation
Electrical connections
430BAL010337EN_7
30 29.07.2021
