5.6
Lubricants
Lubricants
Material no.
Rivolta F.L.G. MD-2
413-071
PARALIQ GTE 703
413-064
5.7
Weights
TYPE GS
Size
Mixproof butterfly valve with drive [kg]
Manual actuator
Pneumatic actuator
without control top
Pneumatic actuator with
T.VIS control top
DN 50, 2"
4.0
7.9
9.1
2 1/2"
5.1
9.0
10.2
DN 65
5.0
8.9
10.1
3"
6.1
10.4
11.8
DN 80
5.9
10.2
11.7
DN 100
8.3
12.4
13.9
4"
8.3
12.4
13.8
Technical data
Lubricants
430BAL010337EN_7
28
29.07.2021
27
29
Table of Contents
Table of Contents
3
General Information
5
Information on the Document
5
Binding Character of These Operating Instructions
5
Notes on the Illustrations
5
Symbols and Highlighting
5
Manufacturer Address
6
Contact
6
EU Declaration of Conformity in Accordance with the EC Machinery Directive 2006/42/EC
7
Translated Copy of the EU - Declaration of Conformity in Accordance with the Pressure Equipment Directive 2006/42/EU
8
Safety
9
Intended Use
9
Flow Speed
9
Pressure Equipment Directive
9
ATEX Directive
9
Improper Operating Conditions
9
Requirements for Operation
10
Operator's Duty of Care
10
Subsequent Changes
11
General Safety Instructions and Dangers
11
Principles for Safe Operation
11
Environmental Protection
11
Electrical Equipment
12
Supplementary Regulations
12
Qualification of Personnel
12
Safety Equipment
13
Signage
13
Residual Dangers
14
Hazard Areas
15
Description
17
Pneumatic Butterfly Valve with Control Top
17
Pneumatic Butterfly Valve Without Control Top
17
Butterfly Valve Body Without Actuator
18
Manual Actuator Type H
18
Functional Description
19
Pneumatic Actuator
19
Actuator (A.1)
19
Actuator (A.2)
19
Manual Actuator Type H
20
Butterfly Valve Body Without Actuator
20
Transport and Storage
22
Storage Conditions
22
Transport
22
Scope of Supply
22
Technical Data
23
Type Plate
23
Resistance of Sealing Materials
25
Pipe Ends - General Table of Measurements
26
Tools
27
Lubricants
28
Weights
28
Assembly and Installation
29
Safety Instructions
29
Notes on Installation
29
Pneumatic Connections
29
Air Requirement
29
Establishing Hose Connections
30
Actuator with T.VIS Control Top
30
Actuator Without Control Top
30
Electrical Connections
30
Electrical Connection with T.VIS Control Top
31
Adjusting the Proximity Switch - Actuator Without T.VIS
31
Start-Up
33
Safety Instructions
33
Notes on Commissioning
33
Operation and Control
34
Safety Instructions
34
Cleaning
35
Cleaning Process Examples
35
Cleaning Effect
35
Cleaning the Leakage Cavity
36
Passivation
37
Maintenance
38
Safety Notes
38
Inspections
39
Pneumatic Connections
39
Electrical Connections
39
Mechanical Connections
39
Signs on the Valve
39
Maintenance Intervals
40
Prior to Disassembly
40
Disassembling the Valve
40
Removing the T.VIS M-15 Control Top
41
Removing the T.VIS A-15 Control Top
42
Removing the Valve
43
Disassembling the Pneumatic Actuator
43
10.5.4.1 Taking off the Actuator
43
10.5.4.2 Dismantling the Actuator Parts
44
Disassembling the Manual Actuator
44
Removing the Valve Disk Seal
45
Maintenance
46
Cleaning the Mixproof Butterfly Valve
46
Lubricating Seals and Threads
47
Installation
48
Assembling the Valve Disk
48
Torques for the Clamps and Bolts
49
Alarms
50
Malfunctions and Remedies
50
Decommissioning
51
Safety Instructions
51
Disposal
51
General Notes
51
Valve Actuator Disposal
51
Parts List - Hygienic Leakage Butterfly Valve Ecospace
52
Spare Parts List - Pneumatic Actuator Hygienic Leakage Butterfly Valve
54
Dimension Sheet - Manual Operation Hygienic Leakage Butterfly Valve
57
Dimension Sheet - Hygienic Leakage Butterfly Valve Ecospace
59
Dimension Sheet - Hygienic Butterfly Valve - Seals
61
Appendix
63
Lists
63
Abbreviations and Terms
63
