Dimensions for Pipes in Inch OD
Inch OD
Outside
diameter
Wall
thickness
Inside
diameter
Outside
diameter acc.
to BS 4825
0.5" 12.7 1.65 9.4 x
0.75" 19.05 1.65 15.75 x
1" 25.4 1.65 22.1 x
1.5" 38.1 1.65 34.8 x
2" 50.8 1.65 47.5 x
2.5" 63.5 1.65 60.2 x
3" 76.2 1.65 72.9 x
4" 101.6 2.11 97.38 x
6" 152.4 2.77 146.86 x
Dimensions for Pipes in Inch IPS
Inch IPS
Outside
diameter
Wall
thickness
Inside
diameter
Outside
diameter
according to
DIN EN ISO
1127
2" 60.3 2 56.3 x
3" 88.9 2.3 84.3 x
4" 114.3 2.3 109.7 x
6" 168.3 2.77 162.76 x
5.5 Tools
List of tools
Tools Material no.
Hose cutter 407-065
Open-end spanners a/f 8; 9; 10; 12; 13; 14; 15;
16; 17; 24
Pin punch Ø 4 403-209
Belt wrench 408-142
Face pin wrench Ø 4, adjustable 80 408-197
Hex. key a/f 3; 4; 5
Installation mandrel 229-000061
Technical data
Tools
430BAL010337EN_7
29.07.2021 27
