Item Designation Material DN 50 DN 65 DN 80 DN 100
Sealing set cpl. EPDM 224-000696 224-000697 224-000698 224-000699
1 Flap BFV-L 1.4404 224-000583 224-000585 224-000540 224-000568
2** Seal BFV-L EPDM 224-000570 224-000571 224-000535 224-000573
3** Radial seal BFV-L EPDM 224-000536 224-000536 224-000536 224-000536
4 Hex head screw A2-70 901-046 901-046 901-046 901-381
8x M8 x 20 16x M8 x 20 16x M8 x 20 16x M10 x 22
15 Cheese head screw A2-70 902-033 902-033 902-033 902-048
2x M10 x 30 4x M10 x 30 4x M10 x 30 4x M12 x 25
18** O-ring EPDM 930-546 930-547 930-450 930-549
19 Flange BFV-LE 1.4404 224-001554 224-001552 224-001555 224-001556
20 VARIVENT smooth flange 1.4404 752-727 752-728 752-729 752-730
21** Plain bearing IGLIDUR-F 704-046 704-046 704-046 704-046
22** Plain bearing IGLIDUR-F 704-069 704-069 704-069 704-069
23 Cap nut M12 x 1.5 1.4571 933-459 933-459 933-459 933-459
24 Cutting ring 6/4 1.4571 933-458 933-458 933-458 933-458
25 Support sleeve 6/4 1.4571 933-380 933-380 933-380 933-380
Grease RIVOLTA F.L.G. MD-2 100g tube not included in the sealing set
Grease BARRIERTA L 55/3 (only for seals VMQ)
413-136
413-137
** The sealing set includes items 2, 3, 18, 21 and 22. 429-045
Item Designation Material 2"OD 2.5"OD 3" OD 4" OD
Sealing set cpl. EPDM 224-000700 224-000701 224-000702 224-000703
1 Flap BFV-L 1.4404 224-000583 224-000584 224-000586 224-000568
2** Seal BFV-L EPDM 224-000570 224-000574 224-000572 224-000573
3** Radial seal BFV-L EPDM 224-000536 224-000536 224-000536 224-000536
4 Hex head screw A2-70 901-046 901-046 901-046 901-381
8x M8 x 20 16x M8 x 20 16x M8 x 20 16x M10 x 22
15 Cheese head screw A2-70 902-033 902-033 902-033 902-048
2x M10 x 30 4x M10 x 30 4x M10 x 30 4x M12 x 25
18** O-ring EPDM 930-559 930-560 930-319 930-561
19 Flange BFV-LE 1.4404 224-001558 224-001553 224-001545 224-001546
20 VARIVENT smooth flange 1.4404 752-741 752-742 752-743 752-744
21** Plain bearing IGLIDUR-F 704-046 704-046 704-046 704-046
22** Plain bearing IGLIDUR-F 704-069 704-069 704-069 704-069
23 Cap nut M12 x 1.5 1.4571 933-459 933-459 933-459 933-459
24 Cutting ring 6/4 1.4571 933-458 933-458 933-458 933-458
25 Support sleeve 6/4 1.4571 933-380 933-380 933-380 933-380
Grease RIVOLTA F.L.G. MD-2 100g tube not included in the sealing set
Grease BARRIERTA L 55/3 (only for seals VMQ)
413-136
413-137
** The sealing set includes items 2, 3, 18, 21 and 22. 429-045
Complete valve bodies can be ordered using the order code.
Select here the actuator type “9 = without actuator”.
e.g. 9771-1002-0900-0000
Parts list - Hygienic leakage butterfly valve ECOspace
430BAL010337EN_7
29.07.2021 53
