Item Designation Material DN 50
2" OD
DN 65
2.5" OD
DN 80
3" OD
DN 100
4" OD
A Actuator BFV-7 / NC/NO/ cpl. -- 224-001822 224-001822 224-001821 224-001821
A (opt.) Actuator BFV-7/NC/NO/cpl./EX -- 224-001831 224-001831 224-001829 224-001829
3 Bracket BFV-7 1.4301 224-001071 224-001071 224-001071 224-001071
5* Cheese head screw A2-70 902-099 902-099 902-099 902-099
7 Elbow screw-in plug connection, metric
(1/4” - 6/4)
Brass/nickel-
plated
933-034 933-034 933-034 933-034
Elbow screw-in plug connection
(1/4"-6.35)
Brass/nickel-
plated
933-972 933-972 933-972 933-972
7.1 Throttle check valve, exhaust air 1/4" Brass/nickel-
plated
603-048 603-048 603-048 603-048
7.2 Screw-in plug connection metric (1/4" -
6/4)
Ms CV 933-480 933-480 933-480 933-480
Screw-in plug connection, metric
(1/4"-6.35)
Brass/nickel-
plated
933-477 933-477 933-477 933-477
8 Hexagon nut A2-70 910-018 910-018 910-018 910-018
9 Initiator M12x1; 10-65V/DC/2wire Synthetic
material
505-104 (electrical connection with terminal compartment)
Initiator M12x1; 10-30V/DC/3wire 1.4301 505-088 (electrical connection with terminal compartment)
505-096 (electrical connection with M12 connector)
11 Position indicator BFV-7 PP 224-001069 224-001069 224-001070 224-001070
12 O-ring NBR 930-041 930-041 930-041 930-041
13 Guide ring Turcite-T51 935-105 935-105 935-105 935-105
14 O-ring NBR 930-903 930-903 930-903 930-903
* Two cylinder screws (pos. 5) are included in each actuator A.
A includes positions A, 3, 8, 11, 12, 13, and 14
Item Material Designation Material no.
Accessories for T.VIS M-15
B Control Top T.VIS M-15 1 1.4301 Switch bar T.VIS 224-001697
Accessories for T.VIS P-15 and A-15
D Control top type T.VIS P-15
and A-15
240 -- Switch bar for T.VIS P-15 and A-15 224-001696
Accessories for control top SES/EX
S Control top SES/EX 220
Switch bar 224-001548
182
Extension 224-001549
Spare parts list - Pneumatic actuator hygienic leakage butterfly valve
430BAL010337EN_7
56 29.07.2021
