2.
Pull the control top (B) upwards.
3.
Remove switch bar.
Ā®
Done
10.5.3 Disconnecting the Valve from the Housing
Fig.13
Notice
Sensitive parts
The surfaces of the balancers are sealing surfaces and must not be
damaged.
āŗ When removing the valve from the pipe take care not to hit the balancer
against the housing. Carefully disassemble the valve.
Carry out the following steps:
1.
Carefully remove the valve insert out of the housing (402).
Ā®
Done
10.5.4 Disassembling the Valve into Individual Parts
Maintenance
Disassembly
430BAL008386EN_3
44 07.02.2022
