Nominal
width
Pipe Housing
Actuato
r
Size Valve
Ø
[mm]
A
[mm]
C
[mm]
C
[mm]
D 1
[mm]
H 1
[mm]
H 2
[mm]
Expansion
X
[mm]
Stroke
S
[mm]
Weight
[kg]
DN 25 29.0 × 1.50 50.0 90 91.0 135 329.0 458.0 718 22 11
DN 40 41.0 × 1.50 62.0 90 129.5 135 338.0 467.0 727 25 14
DN 50 53.0 × 1.50 74.0 90 135.5 135 341.0 470.0 730 30 14
DN 65 70.0 × 2.00 96.0 125 164.5 170 382.0 511.0 916 30 24
DN 80 85.0 × 2.00 111.0 125 172.0 170 399.5 528.5 934 40 26
DN 100 104.0 × 2.00 130.0 125 192.5 170 409.0 538.0 943 40 29
DN 125 129.0 × 2.00 155.0 150 258.0 210 554.5 683.5 1274 60 52
DN 150 154.0 × 2.00 180.0 150 272.5 210 661.0 790.0 1380 60 64
OD 1" 25.4 x 1.65 46.0 90 93.0 135 327.0 456.0 716 18 11
OD 1.5" 38.1 × 1.65 59.0 90 128.0 135 336.5 465.5 726 22 14
OD 2" 50.8 × 1.65 71.5 90 137.0 135 343.0 472.0 732 30 14
OD 2.5" 63.5 × 1.65 90.0 125 167.5 170 386.0 515.0 920 31 24
OD 3" 76.2 × 1.65 103.0 125 176.0 170 402.5 531.5 937 39 25
OD 4" 101.6 × 2.11 127.5 125 194.0 170 411.0 540.0 945 40 31
OD 6" 152.4 × 2.77 177.0 150 274.0 210 659.5 788.5 1379 60 65
IPS 2" 60.3 × 2.00 81.0 114.3 139.0 135 344.5 473.5 734 29 15
IPS 3" 88.9 × 2.30 115.0 152.5 174.0 170 401.5 530.5 936 40 26
IPS 4" 114.3 × 2.30 140.0 152.5 197.5 170 414.0 543.0 948 40 31
IPS 6" 168.2 × 2.77 192.0 152.5 278.5 210 655.0 784.0 1374 60 66
Please keep in mind that a free space of 10-100 mm should be kept under the leakage outlet for this valve type.
Dimension sheet - VARIVENT® double seat valve R
430BAL008386EN_3
76 07.02.2022
