Graphic symbols used
To distinguish between the type and importance of the information provided in these instructions for use, graphic
symbols have been used as a reference to make interpreting the information clearer.
Indicates the contents of the various manual sections,
the general warnings, notes, and other points to
which the reader’s attention should be drawn.
Indicates a particularly delicate situation that
could affect the safety and correct working ope-
ration of the controller, or a rule that must be
strictly observed to avoid dangerous situations
Indicates a condition of risk for the safety of the
user, due to the presence of dangerous voltages
at the points shown
Indicates a suggestion based on the experien-
ce of the GEFRAN Technical Staff, which could
prove especially useful under given cir-
cumstances
Indicates a reference to Detailed Technical
Documents available on the GEFRAN web
site www.gefran.com
In the programming and configuration flows
for the controller, indicates the typical
parameters of the “Easy” configuration,
i.e. the minimum controller configuration
optimized for the basic version that uses
just 2 outputs (OUT1 , OUT2)
In the programming and configuration flows
for the controller, indicates all the parame-
ters that can be set in the “Extended” con-
figuration.
AL.1
AL.2
1 • PRELIMINARY INSTRUCTIONS
This section contains information and warnings of a
general nature which should be read befo-
re proceeding with controller installation,
configuration and use.
General Description
GEFRAN series 1200 / 1300 digital controllers
have been designed for temperature control in
any applications involving heating or cooling
processes. They represent an exclusive combination
of performance, reliability and applicational
flexibility. In particular, this new line of Gefran tempera-
ture controllers is the ideal solution for application
in sectors where performance and service continuity are
important, including:
• extrusionlines
• injectionmoldingforplasticmaterials
• thermoformers
• pressesforrubber
• wrappingandpackagingmachines
• processingplantforthefoodindustry
• coolingswitchboards
• climaticchambersandtestbenches
• ovens
• paintplants
• etc.
The 1200/1300 series temperature controllers are
made on an extremely versatile hardware and software
platform, that allows the most suitable I/O composition
for the plant to be chosen from a series of options, up to
a maximum of:
• 4outputs
• 3inputs(2ofwhichareauxiliary)
• 1RS485interface.
Basic Version Controller
• 1 universal input for TC, 2/3 wire RTD, PTC, NTC,
and linear thermocouples, supplied with current and
voltage with accuracy better than 0.2% f.s.
• 2 standard outputs: one relay and the other
relay/logic/triac (depending on request)
• functions heat/cool, self tuning, autotuning, soft start
• alarm for interrupted load or short-circuited probe
• serviceserial line for configuration by PC (Winstrum)
Options
• 3rd output retransmission relay/
logic/continuous/analogue
• 4th output relay/logic
• 2 auxiliary digital inputs with configurable function,
or 1 auxiliary digital input + current transformer input
to control the load current
• serialoptoisolatedRS485interface
2
81801G_MHW_1200-1300_07-2011_ENG
