7 • TECHNICAL/COMMERCIAL INFORMATION
This section contains information regarding the Controller order codes and the main accessories available.
As stated in the Preliminary Warnings of these Instructions for Use, correct interpretation of the Controller order
code allows the hardware configuration for the controller to be identified immediately and so it is essential to quote
the order code each time the Gefran Customer Care Service is contacted for assistance with any problems.
Order code - Temperature Controller 1200/1300
For information on the availability of codes please contact your Gefran dealer.
100...240Vac/dc
11...27Vac/dc
1
0
2
0
None
RS485
POWER SUPPLY
DIGITAL COMMUNICATION
01
00
None
IN1 + IN2 PNP (NPN)
02
IN1 PNP (NPN) + IN TA (50mAac)
DIGITAL INPUTS IN1, IN2 / AUX TA
R
OUTPUT 1
Relay R
Analogue 0/4...20mA (0...10V) W
OUTPUT 3
None 0
Relay R
Logic D
Continuous 0...10V (0/4...20mA) C
OUTPUT 2
Relay R
Logic D
Triac (1A) T
OUTPUT 4
None 0
Relay R
Logic D
MODEL
1200
1300
36
