APPENDIX
The appendix contains the list of all the abbreviations of parameters which appear in the various configu-
ration/programming menus with the respective default values and meanings.
The CONF column can be used to indicate the user’s modified values with respect to the default configu-
ration, on the basis of application requirements.
Display Default CONF Acronym Description
Livello 1
-SP 400 Local Set Point Local Setpoint setting
SP.1 100 Set Point 1 Setpoint 1 setting
SP.2 200 Set Point 2 Setpoint 2 setting
IN.2 0.0 Input 2 Amperometer input value (TA input)
AL.1 500 ALarm 1 Alarm point 1 setting (Scale Points)
AL.2 600 ALarm 2 Alarm point 2 setting (Scale Points)
AL.3 700 ALarm 3 Alarm point 3 setting (Scale Points)
A.KB 10.0 Alarm HB HB Alarm point setting (Amp. Input
0V.P 100.0 OutPut Control outputs value (+HEAT/-COOL)
Menu INF
UPD 2.01 UPdate Software version identification
(OD 1 Code Instrument code identification
ERR 0 Error Error code detected by self diagnostic
(.KD 1100 Conf Hardware 1 Hardware outputs configuration
(.K2 0 Conf Hardware 2 Hardware inputs configuration
Menu (FG
S.TV 0 Self Tuning Selftuning, Autotuning, Softstart enablement
H.PB 1.0 Heating Hysteresis or heating proportional band
Proportional band
H.IT 4.00 Heating. Integral Integral time for heating
time
H.DT 1.00 Heating derivative Derivative time for heating
time
H.P.K 100.0 Heating Power Maximum power limit for heating
High
H.P.L 0.0 Heating Power Minimum power limit for heating
Low
C.ME 0 Cooling MEdium Cooling fluid type
C.SP 0.0 Cooling SetPoint Cooling Setpoint
C.PB 1.0 Cooling Cooling proportional band
Proportional band
C.IT 4.00 Cooling Integral Integral time for cooling
time
C.DT 1.00 Cooling derivative Derivative time for cooling
time
C.P.K 100.0 Cooling Power Maximum power limit for cooling
High
C.P.L 0.0 Cooling Power Minimum power limit for cooling
Low
RST. 0 ReSet Manual reset
P.RS 0.0 Power reSet Reset power
A.RS 0 Anti - reSet Anti - reset
FFD 0.0 Feed Forward Feed Forward Value
SOF 0.0 SoFt start Softstart time
KY.I -1 HYsteresis 1 Hysteresis for alarm 1
KY.2 -1 HYsteresis 2 Hysteresis for alarm 2
KY.3 -1 HYsteresis 3 Hysteresis for alarm 3
KB.T 30 Hb time Waiting time for HB alarm intervention
LB.T 0.0 Lba time Waiting time for LBA alarm intervention
LB.P 25.0 Lba Power Power limit for LBA alarm condition
FA.P 0.0 Fault Action Power Power output in fault condition
G.SP 0.0 Gradient SetPoint Set Gradient
38
81801G_MHW_1200-1300_07-2011_ENG
