gefran ADL300

ADL300 - Fast installations and commissioning Pag. 49 of 52
5.3.3
11064
Brake open delay (ms)
0
0
10000
Setting of the brake opening delay time.
Menu
Parameter
Description
Default Value
Min
Max
5.3.5
11068
Brake close delay (ms)
200.00
0
10000
Setting of the brake closing delay time.
Menu
Parameter
Description
Default Value
Min
Max
5.3.7
11072
Contactor open delay (ms)
200.00
0
10000
Setting of the contactor opening delay time.
Menu
Parameter
Description
Default Value
Min
Max
5.3.8
11078
Speed 0 threshold (rpm)
1.00
0.01
20
Setting of the zero speed threshold, below which the zero speed signal is activated.
Menu
Parameter
Description
Default Value
Min
Max
5.5.3
11106
Distance multispeed2 (m)
0.00
0.01
10
Setting of the value of the distance associated with multispeed 2.
Menu
Parameter
Description
Default Value
Min
Max
5.5.9
11120
Slow speed
0
0
9
Setting of the floor approach speed.
The Slow speed is the speed of approach to the landing zone. When the multispeed associated with the Slow speed is selected the
slow down space is checked in order to reach this speed in proximity to the landing zone.
0 Autoselect
1 Multispeed 0
2 Multispeed 1
3 Multispeed 2
4 Multispeed 3
5 Multispeed 4
6 Multispeed 5
7 Multispeed 6
8 Multispeed 7
9 Null
When mode 0 (Autoselect) is selected, Slow speed is automatically connected to the multispeed with absolute value of less and other
than zero. If repositioning speeds with a value of less than the Slow speed are used, the multispeed corresponding to the floor approach
speed must be set.
When mode 9 (Null) is selected the floor approach spaces are never controlled. In this case the profile depends exclusively on the
multispeed selected.
Menu
Parameter
Description
Default Value
Min
Max
5.7.4
11226
Multi speed S0 sel
1216
0
35
Setting of the source for the first multispeed selection bit.
1110 Digit input E
1210 Digit input 1x
1212 Digit input 2x
1214 Digit input 3x
1216 Digit input 4x
1218 Digit input 5x
1220 Digit input 6x
1222 Digit input 7x
1224 Digit input 8x
1226 Digit input 9x
1228 Digit input 10x
1230 Digit input 11x
1232 Digit input 12x
3702 Run cont mon
3706 Down cont mon
3708 Brake cont mon
3714 Door open mon
3728 PAD 15
6000 Null
6002 One
12250 B0 Lift decomp
12252 B1 Lift decomp
12254 B2 Lift decomp
12256 B3 Lift decomp
12258 B4 Lift decomp
12260 B5 Lift decomp
12262 B6 Lift decomp
12264 B7 Lift decomp
12266 B8 Lift decomp
12268 B9 Lift decomp
12270 B10 Lift decomp
12272 B11 Lift decomp
12274 B12 Lift decomp
12276 B13 Lift decomp
12278 B14 Lift decomp
12280 B15 Lift decomp
Menu
Parameter
Description
Default Value
Min
Max
5.7.5
11228
Multi speed S1 sel
1218
0
35
Setting of the source for the second multispeed selection bit.
See the list on PAR 11226
