RS5-34 Telescopic Handler DECAL
DECAL LOCATIONS
GENERAL INFORMATION
Decal locations information is provided to assist in
the proper selection and application of new decals, in
the event the original decals become damaged or the
machine is repainted.
For correct replacement of decals, compare the
location illustrations to your machine before starting
to refinish the unit. Check off each required decal
using the illustration reference number to find the
part number, description and quantity in the list.
Refer to the appropriate illustrations for replacement
locations.
NEW DECAL APPLICATION
Before applying the new decals, surfaces must be
free from dirt, dust, grease and other foreign
material. To apply a solid-formed decal, remove the
smaller portion of the decal backing paper and apply
this part of the exposed adhesive backing to the
clean surface while maintaining proper position and
alignment. Slowly peel off the other portion of the
backing paper while applying hand pressure to
smooth out decal surface. To apply a die-cut decal,
first remove the backing paper. Then, properly orient
and position the decal onto the clean mounting
surface. After the decal is firmly applied and
smoothly pressed down, remove any front covering
paper.
Decal Kits
NOTE:
Decals may be purchased in kits or
individually.
WARNING
ALWAYS read and follow the safety
precautions on decals. Replace decals if they
are damaged, or if the unit is repainted. If
repainting, BE SURE that all applicable decals
are affixed in their proper locations.
103369 RS5-34 Telescopic Handler without PWP
103372 RS5-34 Telescopic Handler with PWP
