RS5-34 Telescopic Handler ELECTRICAL
STEERING MODE CIRCUIT TROUBLESHOOTING
Does the steering mode change when the steering mode
switch is moved to different mode positions?
YES NO
Is there 12 volts at the non-functioning mode
solenoid of steering mode control valve?
Is the steer mode fuse open?
YES NO
Replace the coil and/or the steer
mode control valve.
Is there 12 volts at the solenoid
terminal of the steer mode selector
switch?
YES
NO
Repair or replace the wire between
the switch and the solenoid.
Replace the steer mode
selector switch.
NO
Replace the fuse.
Is there 12 volts at the fuse
terminals of the steer mode
selector switch.
YES
YES
NO
Is there 12 volts at the solenoid terminals
of the steer mode selector switch?
Repair or replace the wire between
the fuse and the switch.
YES
NO
Is there 12 volts at the steer mode
selector valve solenoids?
Replace the steer mode selector
switch.
YES
NO
Repair or replace the steer mode selector
valve and/or the valve solenoids.
Repair or replace the wire between
the switch and the solenoids.
