Gehl RS5-34 Service Manual

RS5-34 Telescopic Handler ENGINE
PRINTED IN U.S.A. 201-5 913241
Alt
=
to
hide
template
information
Alt+ to display template information
Template
Name:
OML
_
2
_
col
907871E
Template Date: 1997_02_12
STEP 20
G1159MP
If equipped, place a container under the hoses and
remove the heater hoses from the engine.
NOTE:
There is coolant trapped in the hoses and
engine that will drain when the hoses are removed.
STEP 21
G1158MP
If equipped, remove the hose adapter from the water
pump.
STEP 22
G0905148
Loosen the hose clamps (1) and remove the upper
radiator hose (2).
STEP 23
G0905149
G0905150
Remove the four mounting bolts (1) and the right side
fan guard (2).
1
1
2
1
2
1
1
1
2
