RS5-34 Telescopic Handler ELECTRICAL
STARTER CIRCUIT TROUBLESHOOTING (Cont’d)
YES
NO
YES
NO
YES
NO
YES
YES
NO
YES
NO
NO
Is there 12 volts at the battery
terminal of the key switch?
YES
With the key switch ON, is there
12 volts at the ignition terminal
of the key switch?
NO
Replace the 60 amp in-line
fuse.
YES
Replace the ignition relay.
NO
Replace the key switch.
Use a multimeter to test. Is there
12 volts at the battery terminal
of the starter?
Is there 12 volts at the battery
terminal of the starter relay?
Replace the battery cables
between the starter and the
battery.
With the key switch ON and the starter
switch depressed, is there 12 volts at the
starter terminal of the starter relay?
Replace the battery cable
between the starter and the
starter relay.
Repair or replace the starter
and/or starter solenoid.
With the key switch ON and
the starter switch depressed,
is there 12 volts at the igni-
tion terminal of the starter
relay?
Is there 12 volts at the starter
switch?
Replace the starter relay.
With the starter switch depressed, is there
12 volts at the relay terminal of the starter switch?
Replace the gear selector
switch.
YES
NO
Repair or replace the wire between
the starter switch and starter relay.
Replace the starter switch.
To Next Page
