46 / 64
613, 618
11.2.1 RESET set value input to factory
setting for E1 / E2 / E3
Operating condition
middle LED lit (on)
Press upper and lower buttons longer
than 0.5 sec.
left and right LED lit (on); middle LED
fl ashes
Press upper and lower buttons longer
than 0.5 sec.
left and right LED lit (on); middle LED
fl ickers
factory setting detected
Press upper and lower buttons longer
than 0.5 sec.
middle LED lit (on)
factory setting is saved.
Check the new setting by changing the
signal.
11.2.2 Electric closing limit for E1 / E2 →
reprogramming position of valve
at set value 0 V or 0 / 4 mA
Operating condition
middle LED lit (on)
Press lower button longer than 0.5 sec.
right LED lit (on); middle LED fl ashes
Apply electric signal and change it so that
the motor runs to the desired position.
Press lower button longer than 0.5 sec.
right LED lit (on); middle LED fl ickers
new position of the valve for 0/4 mA is
detected
Press lower button longer than 0.5 sec.
middle LED lit (on)
new position of the valve for 0/4 mA is
saved.
Check the new setting by changing the
signal.
If the new valve position is not okay with a
set value of 0 / 4 mA or 0 V, a RESET must
be conducted (see chapter 11.3.1) and
the entire programming process must be
repeated.
11.2.3 Electric opening limit for E1 / E2
→ reprogramming position of
valve at set value 20 mA
Operating condition
middle LED lit (on)
Press upper button longer than 0.5 sec.
right LED lit (on); middle LED fl ashes
Apply electric signal and change it so that
the motor runs to the desired position.
Press upper button longer than 0.5 sec.
left LED lit (on); middle LED fl ickers
new position of the valve for 20 mA is
detected
Press upper button longer than 0.5 sec.
middle LED lit (on)
new position of the valve for 20 mA is
saved
Check the new setting by changing the
signal.
If the new valve position is not okay with a
set value of 20 mA or 10 V, a RESET must
be conducted (see chapter 11.3.1) and
the entire programming process must be
repeated.
