GEM 613 - Order Data; Order Data GEMÜ

37 / 64
613, 618
7 Order data
7.1 Order data GEMÜ 613
Body configuration Code
2/2-way body D
Connection Code
Threaded sockets DIN ISO 228 1
Solvent cement sockets DIN 2
Union ends with DIN insert (socket) 7
Spigots for IR butt welding, BCF 28
Union ends with inch insert - BS (socket) 33
Union ends with DIN insert (for IR butt welding) 78
Valve body material Code
PVC-U, grey 1
PP, reinforced 5
PVDF 20
Diaphragm material Code
NBR 2
FPM 4
EPDM 14
PTFE/EPDM, PTFE laminated 52
Supply voltage / mains frequency Code
24 V 50/60 Hz C4
120 V 50/60 Hz G4
230 V 50/60 Hz L4
Integrated mounting plate Code
With integrated mounting plate M
only material code 20
Without mounting plate O
only material code 20
Without mounting plate -
material code 1 and 5
Actuator version Code
Operating time 17 sec. A0
Operating time 45 sec. A1
Functional module Code
OPEN / CLOSE control AE
with additional end position feedback
(signal voltage = supply voltage)
OPEN / CLOSE control AP
with potentiometer output
Control of valve position, E1
actual value detection internal,
set value external, 0 - 10 V
Control of valve position, E2
actual value detection internal,
set value external, 0/4 - 20 mA
Control of process variables, E3
actual value external, 0/4 - 20 mA,
set value external, 0/4 - 20 mA
Special version K No.
Potentiometer output with additional end position
feedback - valve position “Closed“
Electrical connection acc. to connection
diagram K-no. 7014
(only with functional module AP)
7014
Order example
613 15 D 7 1 14 C4 AE M A0 -
Type 613
Nominal size 15
Body configuration (code) D
Connection (code) 7
Valve body material (code) 1
Diaphragm material (code) 14
Supply voltage / mains frequency (code) C4
Functional module (code) AE
Integrated mounting plate (code) M
Actuator version (code) A0
Special version (K No.) -
