INSTALLER MANUAL
14.0 - INSTRUCTIONS FOR ALARM SYSTEM
INSTALLATION
:
!
!
Read
inoltre. Moreover, This manual
.
.
.
.
!
!
Before starting the installation procedures, please pay a special
attention to what follows
this manual thoroughly: it includes important information so that a job
can be carried out workmanlike is also an
integral part of the alarm system
All information included in this publication are based on technical
characteristics of GEMINI TECHNOLOGIES S.p.A. alarm system
GEMINI TECHNOLOGIES S.p.A. reserves its right to make any changes
to these characteristics without giving prior notice to its potential buyers
No part of this document can be reproduced without GEMINI
TECHNOLOGIES’s prior written authorization
GEMINI original accessories have been designed for this alarm system
and they have been tested on it.
As the manufacturer cannot check their market availability, the installer or
!
Power supply
Supply voltage range
Load @ 12-Vdc
Currente absorption in
Sound power radiated
Relays capacity
slep-mode
12 Vdc
9Vdc-15Vdc
)
µA
118 dBA @ 1 meter
8A
<0,7mA (system armed and
LED flashing
<1
15.0 - TECHNICAL DATA
16.0 - CONTROL UNIT POSITIONING
!
!
!
!
!
Installing th in this position, will
prevent water entering the unit through the
rubber cap
It is important to position the wiring shealt so
that it forms a kind of siphon.
.
.
e control unit
.
The gearcase must be placed in such a way so
that the siren may play its sound without
restraints and can be shielded against the
weather agents at the same time
The control unit positioning must not be
performed near moving mechanical parts and
electric or electronics parts (which could
generate high intensity electromagnetic
disturbances) as well as near such devices,
which during the vehicle operation could reach
high temperatures.
The alarm gearcase must not be directly
assembled on the vehicle metallic frame
Installing the control unit in this
position, will promote water infiltration
trought the rubber cap.
Note that the water entering the unit
can damage the electronic circuity,
making both the alarm system and
vehicle unreliable.
