Gemini 953 User Manual

23.0 - EXAMPLE OF ENGINE IMMOBILISATION CONNECTION
WITH SPECIFIC WIRING HARNESS
23.0 - EXAMPLE OF ENGINE IMMOBILISATION CONNECTION
WITH SPECIFIC WIRING HARNESS
Ignition key
Ignition key
Ignition key
Ignition key
Vehicle’s electrical equipment
before the installing of the
specific wiring harness
1
2
Disconnect the ignition
connector from
the vehicle’s electrical
equipment
Alarm system
Alarm system
3
Insert the alarm
unit connector
into the vehicle’s
electrical
equipment
Insert the alarm
unit connector
into the ignition
key connector
4
Vehicle’s electrical
equipment connected
with the alarm system
wiring harness
Engine
Engine
Engine
Engine
