Boop
Boop
Beep
Push both remote control buttons at the same time.
The LED will go off.
LED
off
LED
off
LED
off
Turn the ignition key in “OFF” position.
After four seconds have passed, the LED will begin a series of nine flashes.
Turn the ignition key in “ON” when we intends to memorize the first
figure of the new PIN-CODE.
Repeat the same operations described above to insert the other two numbers.
.
When you have finished inserting the fourth number of the PIN-CODE, the
system will automatically exit the procedure and it will confirm the
termination with two low tone acoustic signals and one high tone signal
After four seconds have passed, the LED will begin a new series of nine
flashes.
Repeat the operations described above to insert the second number.
Key in “OFF”
position
Key in “ON”
position
Key in “ON”
position
Key in
“ON”
position
Key in
“OFF”
position
Key in “OFF”
position
Key in “OFF”
position
Last
number
10.0 - EXAMPLE OF PIN-CODE PERSONALIZATION
To better understand how to set up the PIN-CODE, please refer to the example
below.
The following customized PIN-CODE will be entered.2-3-4-1
Connect the BROWN/GREEN
wire to ground.
Remove from negative the
BROWN/GREEN wire.
Open the saddle of the vehicle if the
safety button is fitted.
C
.
lose the saddle of the vehicle if the
safety button is fitted
Turn the ignition key in “ON” position
.
The LED installed on the vehicle will light up for one seconds
During this time period, press both buttons on the remote control.
The system will emit two acoustic signals and then it will light the LED.
Turn off the systemalarm .
Key in position“ON”
0.5
Sec.
Boop
Boop
Fixed
light
NEGATIVE
NEGATIVE
BROWN/GREEN
BROWN/GREEN
To Next Page
