NOMENCLATURE
Rep.
Reference
Designation
1 Y72.26518 FRONT COVER EQUIPPED
2 V72.26643 ISOLATION FRONT COVER
3 Y72.26664 RIGHT HAND SIDE COVER EQUIPPED
4 V72.26624 ISOLATION RIGHT HAND SIDE
5 Y72.26512 FOLDED NECK
6 V72.38386 BOILER SHELL INSULATION STRATON 21
7 V72.26679 PAINTED CONNECTING FLANGE
8 Y72.26677 PAINTED BACK COVER
9 V72.08493 SWIRLERS
10 V72.08531 COMBUSTION CHAMBER
11 F30.11048 MINERAL WOOL 90 KG DISK DIAMETER 262X20
12 V72.28378 FASTENING ANGLE
13 V70.09239 GLASS FIBER ISOLATION LG 950- CAST PLATE
14 F20.28379 FIBER ISOLATION D.280X20 (300°C)
15 H00.28364 BOILER SHELL COVER- CAST IRON
16 Y72.26519 TOP COVER EQUIPPED
17 H20.26493 PROTECTING COVER
18 H20.26489 ABS PROTECTION
19 V72.28409 VALVE STOP
20 V72.36340 CONDENSER TOP
21 E20.36342 TIGHTNESS O’RING CONDENSER TOP
22 V72.26826 FASTENING FLANGE FOR CONDENSER COVER
23 V72.38461 CONDENSOR FCX
24 E20.06892 SEAL AFM34 D. 18,6 X 12 2 MM THICKNESS
25 L90.10142 3 BAR SAFETY RELIEF VALVE
26 Y72.26665 LEFT HAND SIDE COVER EQUIPPED
27 V72.26638 ISOLATION LEFT HAND SIDE
28 L90.00172 CIRCULAR MANOMETER 0/4 BARS
29 T40.38317 KLIXON FIXATION WIRE
30 U72.26516 HEATING RETURN 2. CIRCUIT
31 E20.03889 SEALING AFM34D 30X21X3
32 U72.26515 HEATING RETURN 1. CIRCUIT
33 U72.26517 HEATING FLOW 2. CIRCUIT
34 E20.26827 SEALING ON CONDENSER FLANGE
35 U72.26514 HEATING FLOW DOWN 1. CIRCUIT
36 U72.26786 BOILER SHELL RETURN
37 U72.36680 FLUE OUTLET PIPE FCX Ø 40 LG 185 (PVC)
38 V90.37055 CONNECTING SET VENTOUSE
39 E20.28092 SILICONE SEALING D.162X85X4
40 A10.17552 BLACK HANDLE (FOR H3MG VALVE)
41 K20.03021 REDUCED MESSING NIPPLE M1-M3/4
42 W72.29083 CIRCULATING PUMP UPS 50-130 6H WIRED
43 L85.12296 BRASS VALVE
44 K20.03004 NUT FOR FLANGE 1’’ (FOR PIPE D.22,5)
45 B59.00692 STAINLESS STEEL WASHER 30,4X25,5X0,3
46 T20.00582 SIGHTGLASS PYREX D.30X5
47 L90.03520 EXPANSION CYLIND, VESSEL 8L MALE 3/4 (FCX 20)
47 L90.03639 EXPANSION VESSEL 12L 3/4 CYL (FCX 30)
48 E20.03890 SEALING AFM34 D 24X17X3
49 K50.00584 DRAIN COCK WITHOUT THE CAP F1/2-M1/2
50 U72.26513 HEATING FLOW BEFORE 1. CIRCUIT
51 V72.38386 BOILER SHELL INSULATION STRATON 21
52 U65.29493 AIR FLANGE D.80 LG1500
53 T40.21819 FASTENING FOR THE SENSOR OF THE THERMOMETER
54 V72.38351 CONDENSOR INSULATION STRATON
