- 49 -
NOMENCLATURE
Rep.
Reference
Designation
55 V72.28389 BOILER SHELL COVER EQUIPPED FOR FCX
56 L90.19347 AUTOMATIC DRAIN 3/8 WITH ISOLATING VALVE
57 K20.37049 ELBOW CUPPER NUT 1" - Ø22
58 V72.38465 EQUIPPED BOILER SHELL FCX 22
58 V72.38486 EQUIPED BOILER SHELL FCX 30
59 K10.13600 BEND 90° F3/4-F3/8
60 H20.18800 AQUASTAT KNOB
61 C20.24903 UNIPOLAR REVERSIBLE SWITCH D. 23 BLACK
62 L71.31613 THERMOSTAT 60-80 °C CAP. 1,5M
63 L60.01135 THERMOSTAT RECT HORIZ 69X14 LG CAPIL.1500 MM
64 W72.26691 CONTROL PANEL + STICKER
65 L71.11583 SAFETY THERMOSTAT 110 CAP 1,5M TG400
66 L71.11584 SAFETY THERMOSTAT 120 CAP 1,5M TG400
67 Y72.26694 PAINTED CONTROL BOX
68 C91.12561 WIRE ROPE CLAMP PA 6,6
69 Y72.26696 PAINTED CASING / CONTROL BOX
70 C20.24904 UNIPOLAR SWITCH D. 23 / GREEN LIGHT
71 C91.12561 WIRE ROPE CLAMP PA 6,6
72 C20.24903 UNIPOLAR REVERSIBLE SWITCH D. 23 BLACK
73 C19.24474 SETTING STICK 1014H SP 2311
74 W72.38564 ELECTRIC BOX + WIRING FCX AQUATECH
75 A00.19467 GREY PLASTIC CAP MALE 75
76 B60.34727 SIMPLE SPRING’S PIN D.2 DIN 915
77 V72.38350 POT FOR COMBUSTION CHAMBER LOW STRATON 30
78 V72.12096 CONDENSER CHICANE ( FCX 30 KW )
79 A00.28827 PLASTIC CAP MALE 1/4
* E20.30012 SEAL VITON D.80
* E20.31384 SEAL FOR FRESH AIR INLET PIPE D125
* T10.08829 NYLON BRUSH D. 13 X 60 X 600
* T25.07874 FIXING PIECE FOR THE COVER (MALE)
* T25.26940 BOLT (PVC)
* T40.36749 HOOK GLASS WOOL
* V70.05733 BAFFLE PLATE F400-F E/FEA-FCX (250X200X1,5)
* W72.26495 WIRING S/T FCX
