DISASSEMBLY
PART 6
Section 6.1
Major Disassembly
ITEM QTY. DESCRIPTION
1 7 SCREW, TAPTITE M6-1.0X8 YELLOW
CHROME
2 1 HOUSING, BLOWER GH410 BLACK
3 1 TUBE 410GH OIL FILL/CHECK
4 1 GUARD, F AN
5 1 WRAPPER, BOTT OM
6 6 SCREW, TAPTITE M6-1X10 YELLOW
CHROME
7 1 WRAPPER, TOP
8 1 ASSY, START ER
9 2 SCREW SHC M 8-1.25 X 40 C8.8
10 3 WASHER, LOCK M8-5/16
11 1 BACKPLATE, L/F D/F
12 1 SCREW, HHTT 5/16”-18 X ½” SEMI-
GIMLET
13 1 BREATHER HOSE
14 1 GASKET, INTAKE ADAPTER
15 1 ASSY THROTTLE BODY
16 2 WASHER, F LAT M6
17 4 WASHER, LOCK M6-1/4
18 4 SCREW, SHC M6-1.0 X 20 G12.9
19 1 GASKET,OIL F ILTR ADAPTER
20 1 ADAPTER, OIL FILTER
21 2 SCREW, SHC M8-1.25 X 30 G12.9
ITEM QTY. DESCRIPTION
22 1 SWITCH, OIL 5 PSI
23 1 OIL FILTER
24 1 KEY, WOODRFF 4 X 19D
25 1 FLYWHEEL WITH RING GEAR 27 DEGREE
26 1 WASHER,BELV-20 X 2.2
27 1 NUT , HEX - FLYWHEEL
28 1 SPARKPLUG
32 1 ASSEMBLY, WIRE
33 1 ASSEMBLY, IGNIT ION COIL ADVANCE W/
DIODE
34 2 SCREW HHFC M6-1.0 X 25 FTH G8
38 1 ASSY OIL DRAIN HOSE
39 1 DIPSTICK, GT H410
40 1 O-RING 9/16 X 3/4 X 3/32
41 1 SWITCH, THERMAL 293F
42 3 WASHER FLAT 5/16 - M8
43 2 SCREW, M3-0.5 X 6 SEMS
45 1 GOMMET
48 1 SCREW HHC M8-1.25 x 20
52 1 ENGINE LIF T HOOK
53 1 SCREW HHFCS M6-1.0X10 G8.8
54 1 CLAMP,HOSE OETIKER STEPLESS 17
57 5 SCREW HHFC M6-1.0 X 12
