Generac Power Systems HTS Wn User Manual

38
Section 8 — Exploded Views & Parts Lists
Assembly — Drawing No. 0F6446-D Page 3
ITEM PART NO. QTY. DESCRIPTION
1 0F6610 1 ENCL NEMA 12 36X60X20
2 0F5083 1 DECAL HTS TRANSFER SWITCH
0G3009 1 DECAL HTS T/S
0G3009A 1 DECAL HTS T/S
0G2749 1 DECAL, HTS T/S
3 0F4284 1 KEYPAD COMM XFER SW IN-PHASE
4 095282 1 DECAL-LIVE CIRCUIT
5 0F4302A 1 ASSY, KEYPAD INTERFACE 48" HTS
6 0F4460 2 SPACER M4/#8 X 5/16 X 1/4 NYL
7 0536210193 1 ASSY WIRE #0 12.00" (GROUND
WIRE)
8 077228 1 DECAL-ENCLOSURE NOTE
9 0F5508F 1 DECAL HTS TEST SEQUENCE 600A
0F5508G 1 DECAL HTS TEST SEQUENCE 800A
0F5508H DECAL HTS TEST SEQUENCE 1000A
10 0F5503 1 DECAL SWITCH INFO
11 0D4545 1 DECAL MANUAL OPERATION
12 072164 1 MNL HNDL 6-1600A WN
13 0F4801 1 PLATE MOUNTING PCB ASSEMBLY
14 0F5926 1 ASSY COVER PCB COM XFER SWTCH
15 0F5901 1 ASSY COVER COMM XFER SWITCH
16 0F5180 3 BATTERY AAA
17 * 0F4410 1 ASSY PCB COMM TRANSFORMER
18 * 0G5641A 1 ASSY PCB OTS RELAY-COMM XFERSW
19 0F4802 1 BRACKET TOGGLE SWITCH
20 0D3610 1 DECAL MAINTENANCE DISCONNECT
21 * 055868 1 SWITCH TOGGLE 4PDT 15A SPADE
24 074652 2 TRANSFRM 600V TO 240V 250VA
064932 2 TRANSFRM 480/240V 250VA
25 * 046357 REF. BLOCK TERM 20A 6 X 6 X 1100V
26 0F5039 1 LABEL CPL (CT) TB1
27 * 027911 REF. RELAY PNL 12VDC DPDT 10A@240VA
28 064510 1 DECAL-TERMINAL NOTE
29 063578 1 PLATE DATA - GTS
30 054199 1 DECAL DANGER HIGH VOLTAGE
31 062209 1 DECAL UL LABEL E84929-GTS
32 083736 1 DECAL-CSA GTS
33 0D6584 1 ASSY GRD.TERM.1600-2600A
34 067210A 1 DECAL GROUND LUG
35 * 046689 REF BLOCK TERM 20A 4 X 6 X 1100V
36 0F5040 1 LABEL CPL (RS485) TB2
37 075355 1 DECAL SIGNAL BEFORE XFER
38 0D8700 1 ASSY NEUTRAL BLK 600-1000A ATS
39 0A9457 1 DECAL NEUTRAL
40 091472 1 DUCT WIRING 1 X 1.5 (33”LG)
41 091472A 1 COVER WIRE DUCT 1 IN (33”LG)
42 072111 1 XFRSW 600A 3P WN600V
072117 1 XFRSW 600A 4P WN600V
072112 1 XFRSW 800A 3P WN600V
072118 1 XFRSW 800A 4P WN600V
072113 1 XFRSW1000A 3P WN600V
072119 1 XFRSW1000A 4P WN600V
ITEM PART NO. QTY. DESCRIPTION
43 080433 REF LUG SLDLSS 500-#1X13/32 AL/CU
063925 REF LUG SLDLSS 500-4/0X17/32 AL/CU
44 074349A 2 SW CVR WN 600A 3P
074349B 2 SW CVR WN 600A 4P
074349C 2 SW CVR WN 800/1000A 3P
074349D 2 SW CVR WN 800/1000A 4P
45 0C8308 2 DECAL TERMINAL SHOCK HAZARD
46 * 0F6962$ 1 WIRE HARNESS HTS (NOT SHOWN)
47 0F6888 1 SUB-PLATE HTS 600-2600A
48 0F6776A 1 DECAL, DIP SWITCH CONFIG
49 0F6776B 1 DECAL, DIP SWITCH CONFIG
50 063986 4 KNOB,COVER HOLD-DOWN
51 074351 2 CVR BRKT 600-1600A RH
52 074351A 2 CVR BRKT 600-1600A LH
53 074604 1 AUX CONTACT N-TYP SPDT
54 0F6685 8 TIE-WRAP MOUNT(FIR TREE SYTLE)
55 0C7942 2 HARN STRIP 8"
56 0F9340 1 TAG BATTERY DISCONNECT
57 0G7015 1 TVSS ASSEMBLY 600-2600A
58 0C8095 1 WIRE HARN. STRIP 16"
100 0C6748 2 NUT HEX LOCK M4-0.7 SS NYL INS
101 038150 3 WASHER FLAT #8 ZINC
102 022264 3 WASHER LOCK #8-M4
103 051715 2 NUT HEX M4-0.7 G8 YEL CHR
104 087680 1 NUT WING M6-1.0
105 0D6511 12 SPACER .20 X .375 X .375 PL
106 0E6423 12 NUT HEX FL WHIZ M5-0.8 BOX
107 0C2212 4 SCREW PHTT M4-0.7 X 16 ZYC
108 0A2111 2 SCREW SWAGE #10-32 X 5/16 ZYC
109 0C2267 8 SCREW HHTT M5-0.8 X 12 BP
110 0A1661 REF. RIVET POP .156 X .675 AL
111 022152 8 WASHER LOCK #10
112 024469 8 SCREW HHTT #10-32 X 3/8 CZ
113 022302 REF WASHER LOCK 7/16
114 026209 REF. SCREW HHC 7/16-14 X 1-3/4 G5
115 022509 REF NUT HEX 7/16-14 STEEL
116 067989 REF. NUT HEX FL WHIZ M8-1.25
117 063378 8 HOLDER CABLE TIE
118 091477 7 RIVET WIRE DUCT MNT
119 0F5272 5 CLAMP CABLE FLAT
120 042911 3 SCREW HHC M10-1.5 X 30 G8.8
121 046526 3 WASHER LOCK M10
123 026902 7 SCREW HHTT #8-32 X 1/4 CZ
125 029333A 2 TIE WRAP UL 7.4" X .19" BLK
126 064101 REF NUT HEX FL WHIZ 3/8-16
127 022195 REF WASHER LOCK 1/2
128 022196 REF NUT HEX 1/2-13 STEEL
129 023316 REF SCREW HHC 1/2-13 X 4 G5
130 092980 1 SCREW PPHM M4-0.7 X 25
131 0F7806 7 NUT HEX FL WHIZ M4-0.7
* DESIGNATES ITEMS STRUCTURED IN WIRE HARNESS (NOT SHOWN)
