Section 8 — Exploded Views & Parts Lists
Assembly — Drawing No. 0F7515-D - Page 3
ITEM PART NO. QTY. DESCRIPTION
1 0F7509 1 ENCL NEMA 12 HTS 48 X 72 X 24
2 0F5083 1 DECAL HTS TRANSFER SWITCH
0G3009 1 DECAL HTS T/S
0G3009A 1 DECAL HTS T/S
0G2749 1 DECAL, HTS T/S
3 0F4284 1 KEYPAD COMM XFER SW IN-PHASE
4 095282 1 DECAL-LIVE CIRCUIT
5 0F4302A 1 ASSY KEYPAD INTERFACE 32" HTS
6 0F4460 2 SPACER M4/#8 X 5/16 X 1/4 NYL
7 0536210193 1 ASSY WIRE #0 12.00" (GROUND
WIRE)
8 077228 1 DECAL-ENCLOSURE NOTE
9 0F5508J 1 DECAL HTS TEST SEQUENCE 1200A
0F5508K 1 DECAL HTS TEST SEQUENCE 1600A
10 0F5503 1 DECAL SWITCH INFO
11 074525 1 DECAL MANUAL OPERATION
12 072164 1 MNL HNDL 6-1600A WN (SUPPLIED
W/SW)
13 0F4801 1 PLATE MOUNTING PCB ASSEMBLY
14 0F5926 1 ASSY COVER PCB COM XFER SWTCH
15 0F5901 1 ASSY COVER COMM XFER SWITCH
16 0F5180 3 BATTERY AAA
17 * 0F4410 1 ASSY PCB COMM TRANSFORMER
18 * 0F5641A 1 ASSY PCB OTS RELAY-COMM XFERSW
19 0F4802 1 BRACKET TOGGLE SWITCH
20 0D3610 1 DECAL MAINTENANCE DISCONNECT
21 * 055868 1 SWITCH TOGGLE 4PDT 15A SPADE
24 074653 2 TRANSFRM 600V TO 240V 350VA
064929 2 TRANSFRM 240/480V-120/480V
25 * 046357 REF BLOCK TERM 20A 6 X 6 X 1100V
26 0F5039 1 LABEL CPL (CT) TB1
27 * 027911 REF RELAY PNL 12VDC DPDT 10A@240VA
28 064510 1 DECAL-TERMINAL NOTE
29 063578 1 PLATE DATA - GTS
30 054199 1 DECAL DANGER HIGH VOLTAGE
31 062209 1 DECAL UL LABEL E84929-GTS
32 083736 1 DECAL-CSA GTS
33 0D6584 1 ASSY GRD.TERM.1600-2600A
34 067210A 1 DECAL GROUND LUG
35 * 046689 REF BLOCK TERM 20A 4 X 6 X 1100V
36 0F5040 1 LABEL CPL (RS485) TB2
37 075355 1 DECAL SIGNAL BEFORE XFER
38 0D4203 1 ASSY NEUTRAL BLOCK 1600A ATS
39 0A9457 1 DECAL NEUTRAL
40 091472 1 DUCT WIRING 1 X 1.5 (45” LG)
41 091472A 1 COVER WIRE DUCT 1 IN (45” LG)
ITEM PART NO. QTY. DESCRIPTION
42 072124 1 XFRSW 1200A 3P WN600V
072125 1 XFRSW 1200A 4P WN600V
072114 1 XFRSW 1600A 3P WN600V
072120 1 XFRSW 1600A 4P WN600V
43 063963 REF LUG SLDLSS 750-1/2 X 13/32 AL/CU
44 074349E 2 SW CVR 1200/1600A 3P
074349F 2 SW CVR 1200/1600A 4P
45 0C8308 2 DECAL TERMINAL SHOCK HAZARD
46 * 0F7517$ 1 HARNESS HTS 1200-1600A (NOT
SHOWN)
47 0F6888 1 SUB-PLATE HTS 600-2600A
48 0F6776A 1 DECAL DIP SWITCH CONFIG PCB
COVER
49 0F6776B 1 DECAL DIP SWITCH CONFIG ENCL
50 063986 4 KNOB COVER HOLD-DOWN
51 074351 2 COVER BRACKET 600-1600A RH
52 074351A 2 COVER BRACKET 600-1600A LH
54 0F6685 8 TIE-WRAP MOUNT(FIR TREE SYTLE)
55 0C8095 1 WIRE HARN. STRIP 16"
56 0F9340 1 TAG BATTERY DISCONNECT
57 0C7942 1 HARN STRIP 8"
58 0G7015 1 TVSS ASSEMBLY 600-2600A
100 0C6748 2 NUT HEX LOCK M4-0.7 SS NYL INS
101 0F7806 11 NUT HEX FL WHIZ M4-0.7
104 087680 1 NUT WING M6-1.0
105 0D6511 12 SPACER .20 X .375 X .375 PL
106 0E6423 12 NUT HEX FL WHIZ M5-0.8
107 0C2212 4 SCREW PHTT M4-0.7 X 16 ZYC
108 0A2111 2 SCREW SWAGE #10-32 X 5/16 ZYC
109 0C2267 8 SCREW HHTT M5-0.8 X 12 BP
110 0A1661 REF RIVET POP .156 X .675 AL
111 022152 8 WASHER LOCK #10
112 024469 8 SCREW HHTT #10-32 X 3/8 CZ
113 022237 REF WASHER LOCK 3/8
114 022258 REF SCREW HHC 3/8-16 X 2 G5
115 022241 REF NUT HEX 3/8-16 STEEL
116 067989 REF NUT HEX FL WHIZ M8-1.25
117 063378 8 HOLDER CABLE TIE
118 091477 7 RIVET WIRE DUCT MNT
119 0F5272 5 CLAMP CABLE FLAT
120 042911 4 SCREW HHC M10-1.5 X 30 G8.8
121 046526 4 WASHER LOCK M10
123 026902 7 SCREW HHTT #8-32 X 1/4 CZ
125 029333A 2 TIE WRAP UL 7.4"X .19" BLK
126 064101 REF NUT HEX FL WHIZ 3/8-16
