Generac Power Systems HTS Wn User Manual

50
Section 8 — Exploded Views & Parts Lists
Assembly — Drawing No. 0F8939-E - Page 3
ITEM PART NO. QTY. DESCRIPTION
1 0F8934 1 AV HTS 2000-2600A NEMA12
2 0F5083 1 DECAL HTS TRANSFER SWITCH
0G3009 1 DECAL HTS T/S
0G3009A 1 DECAL HTS T/S
0G2749 1 DECAL, HTS T/S
3 0F4284 1 KEYPAD COMM XFER SW IN-PHASE
4 095282 1 DECAL-LIVE CIRCUIT
5 0F4302A 1 ASSY KEYPAD INTERFACE 32" HTS
6 0F4460 2 SPACER M4/#8 X 5/16 X 1/4 NYL
7 0536210193 1 ASSY WIRE #0 12.00" (GROUND
WIRE)
8 077228 1 DECAL-ENCLOSURE NOTE
9 0F5508L 1 DECAL HTS TEST SEQUENCE 2000A
0F5508M 1 DECAL HTS TEST SEQUENCE 2600A
10 0F5503 1 DECAL SWITCH INFO
11 074525 1 DECAL MANUAL OPERATION
12 072164 1 MNL HNDL 6-1600A WN (SUPPLIED
W/SW)
13 0F4801 1 PLATE MOUNTING PCB ASSEMBLY
14 0F5926 1 ASSY COVER PCB COM XFER SWTCH
15 0F5901 1 ASSY COVER COMM XFER SWITCH
16 0F5180 3 BATTERY AAA
17 * 0F4410 1 ASSY PCB COMM TRANSFORMER
18 * 0G5641A 1 ASSY PCB OTS RELAY-COMM XFERSW
19 0F4802 1 BRACKET TOGGLE SWITCH
20 0D3610 1 DECAL MAINTENANCE DISCONNECT
21 * 055868 1 SWITCH TOGGLE 4PDT 15A SPADE
24 074654 2 TRANSFRM 600V TO 240V 500VA
064933 2 TRANSFRM 240/480V-120/480V
25 * 046357 REF BLOCK TERM 20A 6 X 6 X 1100V
26 0F5039 1 LABEL CPL (CT) TB1
27 * 027911 REF RELAY PNL 12VDC DPDT 10A@240VA
28 064510 1 DECAL-TERMINAL NOTE
29 063578 1 PLATE DATA - GTS
30 054199 1 DECAL DANGER HIGH VOLTAGE
31 062209 1 DECAL UL LABEL E84929-GTS
32 083736 1 DECAL-CSA GTS
33 0D6584 1 ASSY GRD.TERM.1600-2600A
34 067210A 1 DECAL GROUND LUG
35 * 046689 REF BLOCK TERM 20A 4 X 6 X 1100V
36 0F5040 1 LABEL CPL (RS485) TB2
37 075355 1 DECAL SIGNAL BEFORE XFER
38 0D4203 1 ASSY NEUTRAL BLOCK 1600A ATS
39 0A9457 1 DECAL NEUTRAL
40 091472 1 DUCT WIRING 1 X 1.5 (138” LG)
41 091472A 1 COVER WIRE DUCT 1 IN (138” LG)
42 072115 1 XFRSW 2000A 3P WN600V
072121 1 XFRSW 2000A 4P WN600V
072116 1 XFRSW 2600A 3P WN600V
072122 1 XFRSW 2600A 4P WN600V
ITEM PART NO. QTY. DESCRIPTION
43 0F8932A 2 BRKT SWITCH 2000A 3P
0F8932B 2 BRKT SWITCH 2000A 4P-2600A 3P
0F8932C 2 BRKT SWITCH 2600A 4P
44 0D6391 1 SHIELD TRANSFER SW 2000-2600A
45 0C8308 2 DECAL TERMINAL SHOCK HAZARD
46 * 0F8941$ 1 WIRE HARNESS HTS 2000-2600A
(NOT SHOWN)
47 0F6888 1 SUB-PLATE HTS 600-2600A
48 0F6776A 1 DECAL DIP SWITCH CONFIG PCB
COVER
49 0F6776B 1 DECAL DIP SWITCH CONFIG ENCL
53 074672A 1 SWITCH MICRO DPDT SEL & AUX 2PL
55 0C8095 1 WIRE HARN. STRIP 16"
56 0C7942 4 HARN STRIP 8"
57 0F9340 1 TAG BATTERY DISCONNECT
58 0G7015 1 TVSS ASSEMBLY 600-2600A
100 0C6748 2 NUT HEX LOCK M4-0.7 SS NYL INS
101 0F7806 13 NUT HEX FL WHIZ M4-0.7
102 038150 2 WASHER FLAT #8 ZINC
103 022264 2 WASHER LOCK #8-M4
104 087680 1 NUT WING M6-1.0
105 0D6511 12 SPACER .20 X .375 X .375 PL
106 0E6423 12 NUT HEX FL WHIZ M5-0.8
107 0C2212 4 SCREW PHTT M4-0.7 X 16 ZYC
108 0A2111 2 SCREW SWAGE #10-32 X 5/16 ZYC
109 0C2267 8 SCREW HHTT M5-0.8 X 12 BP
110 0A1661 REF RIVET POP .156 X .675 AL
111 092980 2 SCREW PPHM M4-0.7 X 25
113 022237 4 WASHER LOCK 3/8
114 022195 4 WASHER LOCK 1/2
115 022196 4 NUT HEX 1/2-13 STEEL
116 067989 2 NUT HEX FL WHIZ M8-1.25
117 063378 8 HOLDER CABLE TIE
118 091477 5 RIVET WIRE DUCT MNT
119 0F5272 12 CLAMP CABLE FLAT
122 022304 8 WASHER FLAT 1/2 ZINC
123 0A5768 10 WASHER FLAT M10 HEAVY DUTY
124 048610 4 SCREW HHC 1/2-13 X 1 G5
125 029333A 2 TIE WRAP UL 7.4" X .19" BLK
126 064101 REF NUT HEX FL WHIZ 3/8-16
127 022131 4 WASHER FLAT 3/8-M10 ZINC
128 0C6937A 4 INSULATOR STANDOFF 3200V3/8-16
129 029745 4 SCREW HHC 3/8-16 X 1 G5
130 022473 4 WASHER FLAT 1/4-M6 ZINC
131 025870 4 NUT WING 1/4-20
