Genesis 11C - Spreaders

20 WWW.GENESISRESCUE.COM
3.3 Spreaders
S44 S49 S54
S44 S49 S54
Length 35.16 in. 39.33 in. 40.63 in.
Width 9.41 in. 11.10 in. 11.10 in.
Height 8.98 in. 8.98 in. 8.98 in.
Weight (ready for use) 40.12 lbs. 47.62 lbs. 48.06 lbs.
Spreading Width 24.02 in. 28.94 in. 31.7 in.
Pulling Width 18.30 in. 24.41 in. 26.77 in.
Spreading Force in the
Working Area*
9,891.6 - 192,661 lbf 12,364 - 112,629 lbf 11,240 - 112,629 lbf
Max. Pulling Force 15,287 lbf 15,736 lbf 15,062 lbf
Max. Squeezing Force * 33,496 lbf 32,372 lbf 32,372 lbf
Nominal Pressure 10K psi 10K psi 10K psi
EN Class ** AS44/610-18.2 AS55/735-21.6 BS50/805-21.8
Part No. 1101468GRS 1101469GRS 1100143GRS
TECHNICAL SPECIFICATIONS
