4.2 Cutter
1 2 3 4 5 6 7 8 9 10
1 Blades (arms)
2 Protective Cover
3 Handle
4 Cylinder
5 Drive/Pump/Oil Reservoir
6 Rocker Switch
7 On/Off Button
8 Light Control Button
9 Rear Handle
10 Battery Cover and Battery
Brief Description of Cutter
Battery-powered cutters are specially designed rescue equiment for cutting vehicle body parts.
They are used to rescue trapped or enclosed accident victims. The cutter uses include cutting
door and roof beams, columns and sills.
Because the tools are equipped with an internal electrohydraulic drive, they are not linked to
a power unit and can therefore be used in hard-to-reach locations. By using the IP 68 battery
cover, underwater use is also possible.
The movement speed of the shear blades is affected by moving the rocker switch on the
control handle with greater or lesser force. The maximum cutting force is achieved only when
the rocker switch is on full activation.
