Sec-4.7

Setting Open and Close Modes (Constant vs. Momentary Contact)

Before momentary contact control can be used on the CLOSE button, a monitored external reversing

device such as a photocell system or sensing edge switch must be used.

See WIRING SECTION for installation of entrapment protection devices.

WARNING

AVERTISSEMENT

Avant d’utiliser la commande à contact momentané sur le bouton FERMETURE, un dispositif d’inversion

externe surveillée tel qu’un système de cellule photoélectrique ou un commutateur de détection de bord

doit être utilisé.

Voir la section CÂBLAGE pour l’installation des dispositifs de protection contre les piégeages.

Section 4: Programming

NOTE: During adjustment of a travel limit, the open and close modes will automatically fail-safe to constant

contact until the limit has been set. At that time, the open and close modes will revert to their previous setting.

NOTE: Momentary contact (MOM) or Constant Reverse (C-REV) may not be used unless both the OPEN and CLOSE

Limits have been set.

In situations where an external reversing device is either not installed or not operating properly, Constant Contact

(C-STP) MUST BE USED.

OPEN

1. If operator is in RUN mode, press CAL/RUN to enter CALIBRATION MODE.

2. Press SCROLL key until display reads OPEN MODE>MOM or OPEN MODE>C-STP.

• MOM=momentary contact, meaning you press and release the OPEN or pushbutton and the door will

continue to move until it reaches its travel limit. (See NOTE).

• C-STP=constant contact-stop, meaning if you release the OPEN key or pushbutton prior to the door

reaching its travel limit, the door will stop.

3. Press SET/CLEAR key to toggle between OPEN MODE>C-STP or OPEN MODE>MOM on the display.

4. Press CAL/RUN to return to run mode, or continue to CLOSE MODE programming below.

5. If operator is in RUN mode, press CAL/RUN to enter CALIBRATION MODE.

6. Press SCROLL down arrow key until display reads CLOSE MODE>MOM, CLOSE MODE>C-STP or CLOSE

MODE>C-REV.

• MOM=momentary contact, meaning you press and release the CLOSE key or pushbutton and the door

will continue to move until it reaches its travel limit. (See NOTE)

• C-STP=constant contact-stop, meaning if you release the CLOSE key or pushbutton prior to the door

reaching its travel limit, the door will stop.

• C-REV=constant contact-reverse, meaning if you release the CLOSE key or pushbutton prior to the door

reaching its travel limit, the door will reverse direction. (See NOTE)

7. Press SET/CLEAR key to toggle between CLOSE MODE>C-STP or CLOSE MODE>C-REV or CLOSE

MODE>MOM on the display.

8. Press CAL/RUN to return to run mode, or continue to TRANSMITTER PROGRAMMING on next page.

Genie GCL-MJ User Manual
