CONTROL BOARD BRAIN 17
We thank you for having chosen one of our products. GENIUS is certain that from it you will obtain
all the performance you require. All our products are the result of years of experience in the field of
automated systems.
Mains power supply
With power supply switching 230 V~ ± 15% ; 50/60Hz
Power absorbed from mains Stand By = 4W ; MAX about 800 W
MAX load for motors
800 W
Accessories power supply
24 V
"
MAX. accessories current
+24V MAX 500 mA BUS G-WAY MAX 500 mA
LOCK (GENIUS) 12 V~ / 24 V
"
Operating ambient temperature
from -20°C to +55°C
Power supply safety fuses
F1 = 2,5 A
Work time
Self-learned through SETUP - (Max 4 min and 10 sec)
Pause time
Programmable (from 0 to 9 min and 50 sec)
Motor power
Programmable on 50 levels
Connector inputs
RQFZ433/868 Module, USB
Terminal board inputs
Mains power supply, BUS G-WAY, OPEN-A, OPEN-B,
STOP, Photocells during closing, Photocells during ope-
ning, Limit switch
Terminal board outputs
Flashing lamp, Motors, Electric lock (LOCK), W.L. (pro-
grammable), Accessories power supply, failsafe negative
(TX FSW)
1. TECHNICAL SPECIFICATIONS
PURPOSE: this electronic control board has been designed and built to control swing-leaf and/or
sliding gates for vehicle and pedestrian access control.
During programming you can choose between different function logics.
2 programming levels are available from the board (BASIC and ADVANCED), using buttons and LCD
display.
Tab. Technical specifications
