Genius Brain 17 - Advanced Programming Functions

BRAIN 17 24 732788 - Rev. A_1
ENGLISH
5.2 ADVANCED PROGRAMMING FUNCTIONS
Display Advanced Function
Default
rS
REVERSE STROKE WHEN OPENING and RAM STROKE WHEN CLOSING
(NOT displayed if function
FC = 1):
Lets you enable/disable the reverse stroke and ram stroke on swing-leaves.
The reverse stroke facilitates unlatching of the electric lock. When the auto-
matic system is closed, before starting to open, the motors give a brief push
to close.
The ram stroke facilitates latching of the electric lock by activating the motors
at maximum power during final closing.
Y = enabled (for 2 sec)
no = disabled
In case of systems with an absolute encoder, to enable this function
a setup must be performed using the automatic leaf stop on the
mechanical contact point.
no
Od
DELAY FOR OPENING LEAF (visualised only with the function Mn = 2):
You can enable/disable the delay for starting leaf 2 opening with respect to
leaf 1, in order to avoid overlapping of the two leaves.
Y = enabled (for 2 sec)
no = disabled
Y
r1
LEAF 1 DECELERATION:
You can adjust the deceleration space as a percentage of the total travel of
leaf 1.
Adjustable from
00 to 99 %, in 1% steps.
00 = no deceleration
01 = minimum deceleration space
99 = maximum deceleration space
20
r2
LEAF 2 DECELERATION (visualised only with the function Mn = 2):
You can adjust the deceleration space as a percentage of the total travel of
leaf 2.
Adjustable from
00 to 99 %, in 1% steps.
00 = no deceleration
01 = minimum deceleration space
99 = maximum deceleration space
20
